USB - Digital I/O modules TTL

USB - TTL inputs and outputs for the USB interface from Messcomp®

What is TTL?

The term TTL is short for transistor-transistor logic. It is a circuit technology for logic circuits in which bipolar NPN transistors are used as active components. The best-known representatives of this IC series are the LS series with, for example, SN74LS00 etc. The logic family is out of date and has practically no meaning today. Today the term TTL inputs / outputs is used for pure logic inputs / outputs, which normally have no potential separation and at their inputs and outputs certain voltage levels or logic levels are defined for a signal.

USB modules with TTL inputs and/or outputs

The EXDUL® USB modules from Messcomp® with TTL inputs / outputs are ideal for use in the laboratory and for expanding your circuit. The channels can be programmed as TTL inputs or outputs. By accommodating the electronics in the housing of the 37-pin D-Sub connector, the use of the module is particularly space-saving and ideally suited for the problem-free connection of your electronic circuit to a USB interface. The EXDUL® USB module offers a relatively high number of TTL channels at a low price.
